Features
TruGlide Full Extension Racks
Easily extend and hold heavy items on any rack level with the help of roller bearing glides.
Vari-Speed Dual Flow Convection
Maximize airflow and fluffiness with Vari-Speed Dual Flow Convection System. Two-speed convection system capable of turning the fan in both directions. This combined with the largest convection fan blade in the industry provides maximum airflow.
TruConvec Convection Cooking
TruConvec Convection Cooking refers to the exclusive air circulation system employed by Viking convection ovens. Uses only convection element in rear of oven and fan-forced air - no direct heat from top or bottom.
10-Pass Broiler with Heat Reflector
Go from toasting to searing with the variety of settings available on the electric broiler with heat reflector. 10 pass broiler with heat reflector with HI, MED, and LOW settings provides intense searing heat for a variety of broiling applications.
Concealed Bake Element
Get more control and less mess with the 10-pass concealed bake element. This dual concealed bake element provides finer temperature control and makes oven clean up easy.
Rapid Ready Preheat System
Wait less and cook more with the Rapid Ready Preheat System. Quick preheat means less time for the user to wait for the oven to be ready to cook in.
Extra Large Capacity Oven
Cook for everyone you know and still have leftovers with the largest capacity oven in the industry.
TimePiece Clock/Timer
Details
Commercial-Type Cooking Power
Easy Operation and Cleanup
Multiple design options
Exclusive Color Finishes
Model Number
Specifications | |
---|---|
Electrical Requirements | 4-wire ground, 240VAC, 60 Hz, 30-amp electrical connection. Unit equipped with No. 10 ground wire in conduit. Should be fused separately |
Cutout Depth | Standard – 24” (61.0 cm) , Flush mount – 25-3/4” (65.4 cm) |
Cutout Height | Standard – 28-1/8” (71.4 cm) , Flush mount – 30-5/16” (77.0 cm) |
Cutout Width | Standard – 28-1/2” (72.4 cm) , Flush mount – 29-15/16” (76.0 cm) |
Overall Depth from Rear | To control panel – 25-3/4” (65.4 cm) , With door open – 46” (116.8 cm) |
Overall Height | 29-1/2” (74.9 cm) |
Overall Width | 29-1/2” (74.9 cm) |
Approximate Shipping Weight | 261 lb. (118 kg) |
Oven Volume | Overall oven capacity – 4.7 cu. ft. AHAM Standard* – 4.1 cu. ft. |
Interior Dimensions | Width – 25-5/16” (64.3 cm) , Height – 16-1/2” (41.9 cm) , Depth – 16-13/16” (42.7 cm), Three racks, six rack positions |
Maximum Amp Usage | 240VAC – 24.0 amps , 208VAC – 20.8 amps |
